750mAh CP223565 3.0V Li-MnO2 Flat Lithium Battery Manganese Dioxide Cell Non Rechargeable

    Buy cheap 750mAh CP223565 3.0V Li-MnO2 Flat Lithium Battery Manganese Dioxide Cell Non Rechargeable from wholesalers

    Buy cheap 750mAh CP223565 3.0V Li-MnO2 Flat Lithium Battery Manganese Dioxide Cell Non Rechargeable from wholesalers
    • Buy cheap 750mAh CP223565 3.0V Li-MnO2 Flat Lithium Battery Manganese Dioxide Cell Non Rechargeable from wholesalers
    • Buy cheap 750mAh CP223565 3.0V Li-MnO2 Flat Lithium Battery Manganese Dioxide Cell Non Rechargeable from wholesalers

    750mAh CP223565 3.0V Li-MnO2 Flat Lithium Battery Manganese Dioxide Cell Non Rechargeable

    Ask Lasest Price
    Brand Name : HCB
    Model Number : CP223565
    Certification : UN/RoHS/CE/UL
    Price : Negotiable
    Payment Terms : T/T, L/C
    Supply Ability : Two million unit per month
    Delivery Time : 35 work days
    • Product Details
    • Company Profile

    750mAh CP223565 3.0V Li-MnO2 Flat Lithium Battery Manganese Dioxide Cell Non Rechargeable

    750mAh CP223565 3.0V Li-MnO2 Soft Batteries Lithium Manganese Dioxide Cell Non-Rechargeable

    Nominal Capacity750mAh
    Battery discharged at continuous current 1mA until voltage reaches cut-off voltage 2.0V at ambient temperature 23±2℃
    Nominal Voltage3.0 V
    Maximum Continuous Current200mA
    Battery with minimum 50% rated capacity discharged at ambient temperature 23±2℃
    Maximum Pulse Discharge Current500mA
    Battery with minimum 50% rated capacity discharged at max pulse for 3 seconds after 27seconds break. Ambient temperature 23±2℃
    Storage Condition

    Temperature ≤ 30℃

    Humidity ≤ 75%RH

    Operating Temperature-40℃ to +60℃
    Battery DimensionSee drawing on pag
    Max Weight6.5g
    Self-discharge Rate2%
    Max self-discharged rate at ambient temperature 23±2℃
    Shelf Life10 years
    Ambient temperature 23±2℃

    1. Battery Characteristic


    • High Voltage

    Nominal voltage up to 3.0 V

    • High Energy Density

    Energy density up to 450Wh/kg

    • Wide Operating Temperature Range

    -40°C to +70°C

    • Long Shelf Life

    Self discharge rate is less than 2% per year at room temperature
    No passivation effect, instant install-and-use, maintenance free
    Ultra thin

    • Variable Design

    Battery of variable dimensions can be selected to fit in the customer’s design
    Custom batteries and battery packs are also available

    • Greater Safety

    The structure of the battery offers greater safety to meet customer’s requirement for special applications


    2. Main Applications

    • Security & alarms

    Smoke detectors, security alarms, seismometers, locking system, monitoring system, etc.

    • Oil & gas

    Well pressure meters in high temperature, float meter, logging while drilling (LWD), measure while drilling (MWD), etc.
